What are the factors that affect the precision of motor stator winding? How to improve the quality of winding?

The brushless motor stator winding process, is an indispensable part of the production process, due to many friends are not very understanding of the knowledge related to the winding machine, resulting in the purchase of the equipment winding effect is not good, faulty, easy to hurt the line, line breakage, precision is not in line with the requirements of the impact of production, after-sales service can not be guaranteed, then what are the factors affecting the precision of the motor stator winding? How to improve the quality of winding?

1. According to the stator samples to discuss a reasonable winding program, over the line, etc., to ensure that the stator parameters in line with the requirements of the winding.

2. Machine configuration and reasonable design, machine configuration, including servo motors, electric drives, cylinders, guide rails, screws, electrical and frame, base configuration, reasonable configuration and design, machine operation is stable and smooth.

3. The debugging process should be careful, technicians should be experienced, different personnel, debugging machine speed and ability are different, so debugging technology should be excellent.

4. The precision of the stator mold and skeleton, including polishing, grinding, injection molding, etc. to meet the requirements, to ensure that the mold and skeleton without burrs, bumps, to avoid winding scratch, broken wire, etc..

5. The quality of tensioner should meet the requirements, the tension size should be adjusted appropriately to avoid too loose or too tight, resulting in wire breakage, as well as the quality of over-wire wheel, wool felt, wire nozzle, wire tube, etc. should meet the requirements.

What are the factors affecting the precision of motor stator winding? How to improve the quality of winding Vacuz above has made a simple explanation, I hope these tips can help you!
